Liebherr Scientific Atex Tall Fridge SRFfg 4001

SKU: SRFfg 4001

Brand

Leibherr

Scientific Atex Tall Fridge +3/+16?C 394 litre


£2,249.00

About Liebherr Scientific Atex Tall Fridge SRFfg 4001

The Liebherr Scientific ATEX Tall Fridge SRFfg 4001 is a professional, upright laboratory refrigerator in the Performance series, engineered for the secure storage of flammable and temperature-sensitive materials, such as solvents, reagents, and pharmaceuticals, in laboratories and research facilities. Certified to ATEX 95 (EU Directive 2014/34/EU), it offers a 394-liter gross capacity and a temperature range of +3°C to +16°C, ensuring reliable preservation with a maximum temperature fluctuation of ±3°C. Featuring fan-assisted cooling, a digital touch-screen controller, and a hygienic polystyrol liner, the SRFfg 4001 delivers uniform temperature stability and enhanced safety. With integrated alarms, SmartMonitoring compatibility, and compliance with ISO Class 4 cleanroom and GMP Class A standards, it is an energy-efficient solution for critical laboratory applications, backed by Liebherr’s 3-year warranty.

Key Features

  • ATEX 95 Spark-Free Interior: Certified to EN/IEC 60068-3, EN/IEC 61010-1, EN/IEC 61010-2-011, and EU Directive 2014/34/EU (ATEX), with an interior rated for Zone 22 (II 3 G Ex ec IIC T6), ensuring safe storage of flammable substances in closed containers that could form explosive atmospheres.

  • Precise Temperature Stability: Maintains a maximum temperature fluctuation of ±3°C, tested to EN 60068-3 standards by measuring temperature at nine points in the interior, ensuring optimal protection for sensitive materials.

  • Fan-Assisted Cooling: Forced-air cooling system with high-efficiency fans cools freshly stored items rapidly and maintains uniform temperature distribution, eliminating hot and cold spots; automatic defrost enhances efficiency and reduces maintenance.

  • Energy Efficiency: Consumes 421 kWh/year (1.153 kWh/24h) using eco-friendly R600a refrigerant and high-efficiency compressors, minimizing operating costs and environmental impact with low global warming potential.

  • Hygienic Design: Seamless, one-piece polystyrol inner liner is robust, odorless, and fully recyclable, with large corner radii for easy cleaning, meeting ISO EN 14664-1 Class 4 cleanroom and GMP Class A standards for minimal particulate contamination.

  • Advanced Monitoring: 2.4″ touch-screen controller with built-in data logger, min./max. temperature log, and HACCP-compliant documentation; optional SmartMonitoring via retrofittable WiFi/LAN interface for cloud-based temperature monitoring and alarms.

  • Safety and Security: Features a mechanical lock with two keys, visual/audible alarms for temperature deviations, power failure, and sensor defects, volt-free alarm contact for external systems, +2°C SafetyDevice to prevent freezing, and an alarm test function for system reliability.

  • Flexible Configuration: Reversible door hinges (factory-set to right) without additional parts, 5 adjustable glass shelves (40kg load each), and a Ø10mm feedthrough for external sensors for installation flexibility.

  • User-Friendly Controls: Flush-integrated control panel with a dirt-resistant membrane keyboard, self-explanatory menu with three touch buttons, demo mode for training, and support for 19 languages; displays serial and service numbers for easy access.

  • Low Maintenance: Operates without filters, with automatic defrost and replaceable plug-in door seals for tool-free replacement; self-closing door (<90°) enhances convenience; requires only regular cleaning and calibration; operates quietly at 49 dB(A).

Applications

  • Chemical Laboratories: Safely stores flammable solvents and chemicals in closed containers, meeting ATEX 95 safety standards for explosive atmospheres.

  • Pharmaceutical Laboratories: Preserves temperature-sensitive pharmaceuticals and reagents with precise temperature control, ensuring compliance with GMP Class A standards.

  • Medical and Biological Research: Maintains specimens and cultures at consistent temperatures for reliable research outcomes.

  • Cleanroom Environments: Certified for ISO Class 4 cleanroom use, ideal for applications requiring strict hygiene and minimal particulate contamination.

  • Healthcare Facilities: Provides secure storage for medical samples and compounds, with monitoring features to meet stringent quality requirements.

Attributes

  • Model: SRFfg 4001 Performance

  • Dimensions:

    • External (H/W/D): 1884 x 597 x 654 mm

    • Internal (H/W/D): 1244 x 460 x 440 mm

  • Capacity:

    • Gross: 394 liters

    • Net: 298 liters

  • Temperature Range: +3°C to +16°C (factory pre-set to +5°C)

  • Energy Consumption: 421 kWh/year; 1.153 kWh/24h

  • Cooling System: Fan-assisted with automatic defrost, R600a refrigerant

  • Shelves: 5 adjustable glass shelves (40kg load each)

  • Door Configuration: Reversible, right-hinged standard, self-closing <90°, solid door

  • Safety Features: +2°C SafetyDevice, visual/audible alarms, volt-free alarm contact, mechanical lock, integrated data logger, power failure alarm, alarm test function

  • Compliance: ATEX 95 (EU Directive 2014/34/EU), EN 60068-3, ISO EN 14664-1 Class 4 cleanroom, GMP Class A, HACCP-compliant, IEC 61010-2-011

  • Power Supply: 220-240V, 50Hz

  • Sound Rating: 49 dB(A)

  • Net Weight: 69 kg

  • Warranty: 3 years on scientific and healthcare products

  • Safety Warnings: Follow user manual for safe operation; ensure 2.5 cm free space around appliance for ventilation; store flammable materials in closed containers per ATEX guidelines; regular cleaning of drain hole required; contact Liebherr Customer Service for maintenance or seal replacement.

Downloads


Operating Instructions, SRFfg 4001


Purchase

£2,249.00
